Large Diameter Rotary Blade Wire Stripping Machine

  • Model:KS-W668
  • Net. Weight:
  • Dimension:
  • Light and portable;

  • Robust & reliable:

  • Excellent price/performance ratio;

  • Easy to operate and have extremely short cycle times;

  • Support full stripping, half stripping, multi-layer stripping and twisting;

  • The top-quality, durable blades and components enable high processing speeds, which reduces throughput times accordingly;

Download: (1)

Suitable Material:Coaxial cable, triaxial cable, shielded cable, TV signal cable, audio cable etc.

Display Mode:Color touch screen

Operating Mode:Foot switch/Manual

Display Language:Chinese/English

Available Wire Size:Ф12mm~Ф45mm

Tolerance:0.01mm

Stripping Method:Rotary Blade

Driving Mode:Motor/ball screw drive

Power Supply:220V 50Hz/110V 60Hz

Net. Weight:151Kg

Stripping Length:0~200mm

Centering Slice:4pcs

Blade Quantity:4pcs

Blade Material:Tungsten Steel

Max. Stripping Layer:9 layers

Storage Capacity:99 sets of programs

Capacity:200~500 pcs/hour

Dimension:1200*340*500mm

Note:

  • The above specifications are for reference only. In the case of extremely hard, tough wires, processing may not be possible even within the cross section range. In case of doubt, KINGSING will be happy to provide processing samples of your wires.

  • Conforms to the relevant CE directives on machine safety and electromagnetic compatibility.
