Rotary Blade Cable Stripping Machine

  • Model:KS-W66 series
  • Net. Weight:
  • Dimension:

1、This series of wire stripping machines includes 2 sub-models, which are suitable for processing various coaxial cables, automotive cables, medical cables, high temperature wires, new energy wires, etc. It uses 4 pieces of high-precision tungsten steel blades to rotate and strip the wires, and the maximum outer diameter of the stripped wires can reach 34mm. The rotating blade can cut the stripping position 360 degrees, the stripping mouth is smooth and smooth, the stripping length is precise, the cutting accuracy can reach 0.01mm, and the inner layer will not be damaged.

2、Color touch screen operation interface, parameter setting is intuitive and easy to understand. It can be stripped in up to 9 layers, and the cutting depth and stripping length of each layer can be freely set in the program. For example, when stripping a coaxial cable, the outer layer, braided layer, and core wire can be stripped to different lengths. Up to 99 groups of programs can be saved, and the processing parameters of different wire materials can be saved in different program numbers. When switching wire materials, the corresponding parameters can be called out with one key without mechanical adjustment.

ModelKS-W6641KS-W667
Applicable wire diameterΦ6~34mmΦ3.5mm~Ф33.5mm
Max stripping length0~150mm0~200mm
Rated power800W800W
Net weight
108kg153kg
Dimensions1000*285*490mm1150*300*450mm

Blade Quantity: 4 pcs

Tolerance: 0.01mm

Max.stripping layer: 9 layers

Capacity: 200~500 pcs/hour

Storage capacity: 99 sets of programs

Power Supply: 220V 50Hz/110V 60Hz

Note:

  • The above specifications are for reference only. In the case of extremely hard, tough wires, processing may not be possible even within the cross section range. In case of doubt, KINGSING will be happy to provide processing samples of your wires.

  • Conforms to the relevant CE directives on machine safety and electromagnetic compatibility.
