HV Cable Processing Line

  • Model:KS-C001BF
  • Net. Weight:
  • Dimension:

This machine is specially designed for processing new energy high-voltage wire harnesses and is used for pretreatment before crimping HV cables. It can automatically complete the processes of stripping cable outer sheath, laser cutting aluminum foil, cutting and braiding, turning over braiding, and stripping cable inner sheath. The laser aluminum foil removal process does not damage the inner layer, and the aluminum foil residue is less than 2mm. The shortest braiding length reserved for cut braiding can be up to 5mm, and the maximum length for turned over braiding can be up to 30mm. One machine can be used for a variety of different wire diameters, and is suitable for processing high-voltage cables from 3 to 70 mm2.

Download: (1) (2)

Wire range:3 mm2 -70 mm2

Wire sheath wall thickness T:0.7mm-1.5mm

Stripped wire sheath length range:10mm-100mm

Laser removal of aluminum foil:the residual aluminum foil is less than 2mm

Cut braided mesh retention range:the shortest 5mm (different wire diameters need to change the blade)

The range of the braided mesh:up to 30mm (different wire diameters need to change the casing)

Stripped wire inner length range:10mm-90mm

Poiwer requirements:AC 220V  50HZ/60HZ

Processing efficiency:200-250PCS/H

Power:about 6kw

Dimension:2700 * 1800 * 2200mm

Weight:about 850kg


  • The above specifications are for reference only. In the case of extremely hard, tough wires, processing may not be possible even within the cross section range. In case of doubt, KINGSING will be happy to provide processing samples of your wires.

  • Conforms to the relevant CE directives on machine safety and electromagnetic compatibility.
